| Model | PB8012 |
| Type | Manual Pan and Box Brake |
| Max Bending Length | 80 in (2032 mm) |
| Max Bending Thickness | 12 Gauge Mild Steel (2.5 mm) |
| Bending Angle | 0° to 135° |
| Max Box Depth | 6 in (152 mm) |
| Shut Height | 4 in (102 mm) |
| Max Lift of Beam | 1 in (25 mm) |
| Beam Adjustment | Manual |
| Finger Configuration | 11″ x 3 pcs, 6″ x 3 pcs, 5″ x 3 pcs, 4″ x 2 pcs, 3″ x 2 pcs |
| Material | High-strength Steel Frame |
| Max Capacity | 12 Gauge Mild Steel (0.105 in, 2.5 mm) |
| Beam Type | Box Beam with Reinforced Ribs |
| Packaging Dimensions | 100″ x 30″ x 40″ (2540 mm x 760 mm x 1016 mm) |
| Shipping Weight | Approx. 2,631 lbs (1036 kg) |
WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
